M850-00
Tools Required
I1.1
Copyright TEL 31/09/98
1 Tools Required
Tool Size
Allen Head Screwdriver 2mm AF
Flat Blade Screwdriver 3mm AF
Pozidriv Screwdrivers No. 1 for M3 screws No. 2 for M4 screws
Torx Screwdrivers T10 for M3 screws T20 for M4 screws
Spanners 1/4” AF for D-range locating pins
5.5mm AF for M3 nuts
a
6mm AF for SMC connector
7mm AF for M4 nuts
a. If you do not have a 5.5mm spanner, you can use long-nosed pliers to carefully grip the M3 nuts on
the D-range securing screws and locating pins.
Solder
Soldering Iron
To Next Page
