M850-00
T858/859 SII - SI Conversion
I3.1
Copyright TEL 31/09/98
3 T858/859 SII - SI Conversion
3.1 Introduction
You must make a number of modifications to enable a T850 Series II PA to operate in a
Series I rack frame. These changes can be split into two groups, mechanical and electri-
cal, as described below.
This procedure assumes you have already purchased the appropriate Series I conver-
sion kit:
• T858 - T800-70-0058
• T859 - T800-70-0059.
If not, you should purchase one from your nearest Tait Dealer or Customer Service
Organisation before beginning the procedure.
It should take approximately 15-20 minutes per module to perform these steps.
Mechanical These changes involve putting on a new front panel because of the
differences in height and width between a Series II and Series I
panel.
Electrical These changes involve converting the PA from rear RF input to
front RF input.
