Tait TB8100 Installation Guide

28 Connection TB8100 Installation Guide
© Tait Electronics Limited February 2007
Table 2.2 Differences between the TaitNet Ethernet D-range connector
and other TaitNet connectors
Pin TaitNet Ethernet Signal Name
Tait Net and Tait N et R S-2 32
Signal Name
10 digital in/out 1 digital out 3
11 RSSI no connection
12 digital in/out 2 digital out 1
13 digital in/out 3 digital out 2
14 digital in/out 4 digital in 1
Figure 2.2 Setting switches S1 and S2 on the TaitNet Ethernet system interface board
S1
S1
S2
S2
1
2
345
6
78
ON
1
2
345
6
78
ON
1
2
345
6
78
ON
1
2
345
6
78
ON
Factory default settings
Rx gate, Tx Key, unbalanced audio
S1
S2
Optional settings
E&M signalling
RSSI
Tx relay
switches 1 to 6 not used
switches 1 to 6 not used
