Table 2.1 Pin allocations for the TaitNet Ethernet D-range connector
Pin Signal Name
Switch S1 &
S2 Settings
Signal Type NotesOn Off
1 Rx line out +
audio output
transformer isolated
line
2 Rx line out –
3 Rx audio out
a
or
S1:5 S1:6 audio output
opto +/– S1:6 S1:5 isolated
keying input
input voltage range
±10VDC to ±60VDC
4Rx gate
a
or
S1:3 S1:4 output open collector
relay +/– S1:4 S1:3 isolated gate
output
5 Tx key
a
or
S1:7 S1:8 input
relay –/+ S1:8 S1:7 isolated gate
output
6Tx audio in
a
or
S1:1 S1:2 audio input
opto –/+ S1:2 S1:1 isolated
keying input
input voltage range
±10VDC to ±60VDC
7Tx line in +
audio input
transformer isolated
line
8Tx line in –
9 +AUX_V power output from auxiliary DC input
10 digital in/out 1
bc
input 5V TTL logic, active low
11 RSSI
a
or
S2:8 S2:7 DC signal
Tx relay S2:7 S2:8 output open collector
12 digital in/out 2
b
input 5V TTL logic, active low13 digital in/out 3
b
14 digital in/out 4
b
15 ground ground
a. Factory default settings.
b. Digital inputs 1, 2, 3, and 4 may also be configured as outputs using a Task Manager statement. For more details
refer to “Digital Interface” in the “Connection” chapter of the Installation and Operation Manual, and to the Serv-
ice Kit documentation.
c. If a base station with a 12V PA is configured for Deep Sleep, digital out 1 is dedicated to Power Saving control and
cannot be used for any other Task Manager function.
external view
J
B
C
D
E
F
G
H
I
1)
1!
1@
1#
1$
1%
