16 Using the CTU with a TB7100 TBA0STU/TBA0STP CTU Operation Manual
© Tait Electronics Limited September 2005
Figure 3.2 Example CTU connection to a TB7100
25-way cable
TB7100 CTU
adaptor board
Power
System Interface
To PC running
Programming or
Calibration Application
T2000-A19 programming lead
plus TMAA20-04 adaptor
(recommended)
TB7100
CTU
