Midian Encryption Programming and Service Manual Midian Encryption 19
June 2006 © Tait Electronics Limited
TVS2-Tait Over-the-Air Programming
The Midian TVS2-Tait Module encryption code can be remotely changed.
Contact your Tait Service Centre for more information.
TVS2-Tait Direct Programming
A radio with Midian TVS2-Tait Encryption Module can be direct-
programmed without opening the radio, to change any of its programmable
parameters. This requires a dedicated direct programming cable as follows:
TOP radios use 219-02931-0X (see Cable Specifications on page 25)
TM8000 radios use 219-03026-0X (see Cable Specifications on page 25)
Note The Midian KL3 programmer includes a dedicated programming
cable. However, as this cable requires the radios to be opened, its
use is not recommended or supported by Tait.
Direct Programming
Method
Equipment
PC with serial port, and if necessary 25pin D-range plug to 9 pin D-
range socket adaptor.
Midian KL3 programmer (supplied cable not required).
Midian software to suit the module to be programmed.
TVS-2 encrypted TOP or TM8000 radio to be programmed
Encryption Direct Programming Cable 219-02931-0X (TOP) or 219-
03026-0X (TM8000)
Setup
connect cable to
15way D-range
on radio rear
TM8000 Encryption Direct
Programming Cable
Connect cable to TOP
accessory connector
TOP Encryption Direct
Programming Cable
RS232 serial cable
(not provided)
or
