Tajfun EGV 45A - Releasing the Wire Rope under Load

10
4.3. RELEASING THE WIRE ROPE UNDER LOAD (Figure 4)
 The brake prevents tied load from sliding back, when you stop the pull.
 Release the stretched wire rope, by quickly pulling the white string 21 of the brake handle
20.
WARNING:
 When releasing the wire rope, pull the string lightly to prevent brake handle from
blocking in the “permanent brake release” position, otherwise the drum may uncoil
suddenly and the coiled wire rope may loosen.
If the wire rope on the drum gets loose, the outer coils of the wire rope get under the inner
coils at the repeated pulling, and the wire rope gets damaged quickly.
4
H
21
20
11
10
