To increase embroidering efficiency
124
Chapter 5
PT03
8-3. To collect up frame moving amount of consecutive jump stitches in a batch to feed the
frame all at once (Jump code combination)
This function reduces the number of stitches by combining frame moving amount of consecutive jump
stitches (up to 5 stitches) and by feeding the frame all at once.
8-3-1. Explanation on the screen
8-3-2. How to operate
The following is an example that Jump Code Combination is set.
(1) To open screen
(2) To set Jump Code Combination
8-4. To change moving speed of needle bar case (Color change speed)
8-4-1. Explanation on the screen
YES: To set
NO: Not to set
High: High speed (usual setting)
Low: Low speed
5 Jump Code Combination
NO
5 Jump Code Combination
NO
