To edit design
136
Chapter 5
(8) To select "Jump".
(9) To decide insertion
9-3. To delete the stitch (Data Edit "Delete")
When this operation is performed in the middle of embroidery, data set will be canceled. If the stitch having
length is deleted, a design will displace hereafter.
9-3-1. Explanation on the screen
Jump
Are you ready ?
1 Data Edit
Delete
1
2
3
4
5
6
7
8
9
10
0 0 Jump
84Stitch
83Stitch
11 5 Stitch
88Stitch
113Stitch
-11 2 Stitch
-12 -3 Stitch
-11 7 Stitch
-25 15 Stitch
Modify
Insert
Stitch No.
X data (Data to move the frame in X-axis
direction)
When the value is 8, the frame travel amount is
0.8 mm.
Y data (Data to move the frame in Y-axis
direction)
When the value is 4, the frame travel amount
is 0.4 mm.
Function Code (p.251)
It is the code to indicate the role of the stitch.
