Necessary works after replacing the frame
164
Chapter 6
PT10
To set the frame type to "A. clamp T" (Auto Clamp T), follow the procedure below.
To perform "Frame Origin Memory", follow the procedure below. The frame could hit the
machine depending on the position of the frame, and it might cause the damage of the
parts.
The center of embroidery space
Upper right position
Pressing SET key will move the frame.
Frame origin memory
"YES">>SET
Code No. 5C1 will
appear.
Move the frame to the upper
right position from the center of
the embroidery space by manual
frame travel.
Perform operation of "Frame Origin
Memory". (SET+F2)
Press E key.
Press the stop switch
immediately after moving
the frame.
STOP
is executed.
CAUTION
!
