What to do when the machine stopped
221
Chapter 9
1
2
3
4
5
6
7
8
9
10
11
UO04
1-2. Abnormal stop
It is displayed in red on the screen. The trouble will occur when the movement of the machine comes off from
normal position etc.
No. Stop factor How to restore
211
The main shaft has stopped deviating from the fixed
position.
Return the main shaft to the fixed position. Check
the main shaft fixed position sensor.
221
(*)
The embroidery frame moved to the travel limit
position (left) (+X direction).
Move the frame manually so that embroidery can be
performed within the set range.
222
(*)
The embroidery frame moved to the travel limit
position (right) (-X direction).
223
(*)
The embroidery frame moved to the travel limit
position (front) (+Y direction).
224
(*)
The embroidery frame moved to the travel limit
position (rear) (-Y direction).
225
The frame move to the limit position during trace. Press the E key. Check the current frame position.
The frame moved to the software limit position
during trace.
Press the E key. Check setting range of software
frame limit.
228
Table up/down operation was performed when the
frame was positioned at the front.
Move the frame to the rearmost position.
229 The machine was stopped during Power resume. Perform Power Resume again.
251 Oil of lubricating pump is lacking. Lubricate to the lubrication tank.
274 Presser foot error (TMBR-SC)
Turn "OFF/ON" the power. Check or replace the
control card.
291
Upper thread breakage is detected. Check thread.
TC sensor card error Replace TC sensor card.
293 Under thread breakage is detected. Check under thread.
2B1 Network does not work normally.
Check connecting status of cable, setting status of
device such as personal computer.
2B3 Data exists in an end code.
Correct design data.2B4 Function code error
2B5 Sequin data error
2B7 Data set is not completed. Set data.
Wrong setting for optional device
Check the setting for option.
[2C2]
"Reset" >>E
Code No.
Stop factor
To Next Page
