5. Electrical system diagram
The harness number in the figure accords with the table number on the next
page.
Operation panel
7-inch wide type
LCD
Switch card
CPU card
Connector card USB hub card
Power cord
AC
Inlet
Emergency stop switch
Circuit protector
24 V DC
Power supply
Noise filter
Main shaft card
AC Inlet
Noise filter
Thermal type
Rocker switch
Power cord
5 V DC
Power supply
Emergency stop switch
24 V DC
Power supply
Option card
Sequin motor
valve
Signal tower
Air pressure
Beam sensor
Line marker
LED light
Needle Base LED Light
Picker solenoid
Upper thread lock solenoid
Position marker
Permanent counter
Foot switch
Color change potentiometer
Thread breakage sensor
Jump motor ATH motor
Control card
Y-axis motor Encoder
Y-axis origin sensor Auto clamp sensor ATH origin sensor X-axis origin sensor
Encoder X-axis motor
Color change motor Hook motor
Presser foot motor (*) Encoder (*)
Encoder Main shaft motor
Fan
AC power supply 24 V DC 5 V DC
Control signal Control signal Control signal
Upper shaft sensor
3.3 V DC
Grounding
EN-spec.
[A]
To [A]
To [B]
[B]
(*) TMBR only
