How to use each part
18
Chapter 2
UO04
2-3. Needle Base LED Lamp
The needle base LED lamp can be lit or unlit by the operation panel.
2-4. To suspend a head
By pressing the thread breakage indicator lamp while pressing SET key in the state of main screen, the state
of the head (operation pos
sible/suspended) will be switched. The state after switching can be confirmed on
main screen.
Needle Base LED Light
How to turn ON or OFF needle base LED lamp
(1) Press D2 key to select "9 Needle base LED
light".
(2) Select ON/OFF by using the jog dial, and
press SET
key.
ON: Lit
OFF: Unlit
F1
A
AS
FB
START STOP
BC
E
SET
D1 D2
F2 F3 F4
0Y:- 100.0
Thread breakage indicator lamp
Operation possible
To suspend
Set key
