Check items before embroidering
62
Chapter 4
SQ06
6. Check items before embroidering
6-1. Maximum speed (Maximum RPM)
The value set here will be the maximum speed of the machine. It is automatically increased/decreased
depending on stitch length in the middle of embroidery.
6-1-1. Explanation on the screen
6-1-2. How to operate
The following is an example when setting the maximum speed to "950".
(1) To open screen
Stitch length
Embroidery speed
Up to 4.0 mm
Maximum speed
(A in the right figure)
4.1 mm to 11.9 mm
Automatic change
(B in the right figure)
12.0 mm or more Low speed (C in the right figure)
Maximum speed
1000
Speed display column
During stop: The maximum speed is displayed.
During operation: Actual operating speed is
displayed.
0
To Next Page
