197
OPTIONS
Safety Signs (Decals)
1. No.03593-32200
2. No.03593-32300
G
A
(ISO)
03593-32200
03593-32300
Check what type of lever control
arrangement you are operating
with before beginning operations.
WARNING
3. No.03593-30100 <TB125>
3. No.03793-27100 <TB135>
3. No.03993-28100 <TB145>
4. No.05693-53810
05693-53810
Setting this switch to the
OFF
position will shut down
all of the electrical circuits and
the memory of the radio preset
tuning buttons will be deleted.
CAUTION
