Takeuchi TB145 User Manual

199
OPTIONS
Switching the Lever Pattern
1. Park the machine in a safe place and turn
off the engine.
2. Fully open the cab door and fix it in place.
3. Lift up the floor mat at the cab entrance.
4. Open the cover (1).
5. Loosen the wing bolt (2).
6. Turn the selector valve lever (3) and switch
the pattern.
7. Tighten the wing bolt (2) and fasten the
lever (3) in place.
8. Close the cover (1) and set the floor mat
back in place.
9. Check the lever pattern.
The operating pattern of the left and right operating levers can be changed.
WARNING
Before starting the engine, check the selector to see which operating pattern the left
and right operating levers are set for.
Switching the Lever Pattern
(A) : ISO pattern
(G): JCB pattern
ISO
A
JCB
G
C4L004
L3L0021
2
3
G
A
1
