1. Low Cut:
1) Switch to " ": records sound as it is, generally used in a quiet
environment (e.g., anechoic room).
2) Switch to " ": filters out low-frequency environmental noise below
150Hz (e.g., traffic, air-conditioner, stage floor vibration), and effectively
reduces plosives for clearer sound.
2. Attenuation Pad:
1) Switch to "0dB": no attenuation.
2) Switch to "-10dB": attenuates sensitivity by 10dB for recording higher
sound pressure, usually used in areas with high SPL (e.g., instruments like
bass drum, trumpet in a symphony orchestra).
Attenuation PadLow Cut
10
Function Descriptions
11
Professional Recording Microphone
PC-K600
Professional Recording Microphone
PC-K600
• Capsule: ø34mm gold-plated large-diaphragm condenser
• Polar Pattern: cardioid• Frequency Response: 20Hz-20KHz
• Sensitivity: -33dB±3dB (0dB=1V/Pa at 1KHz)
• Equivalent Noise Level: ≦20dB (IEC 581-5)
• Peak SPL: 130dB (THD≤1% at 1KHz)
• Output Impedance: 100Ω±30% (at 1KHz)
• Sensitivity Attenuation: -10dB
• Low Cut: 100Hz 10dB/Oct
• Power Requirement: 48V phantom power
• Dimensions: ø50mm×188mm
• Weight: 480g
-80
-100
210°
120°
240°
-30
330°
300°
270°
60°
90°
180°
150°
30°
0°
Specifications
Frequency Response Curve
Note: The above data are measured by Takstar laboratory which has the final
interpretation right!
