Installation: (B-1200-R)
1. Turn o water supply and drain
lines. Hand tighten no.20 rmly
against no.1 and remove no.21 from
no.1.
Installation: (B-1210-R)
1. Turn o water supply and drain
lines.
2. Unscrew and remove no.26 and
no.25 from no.23. Position no.24 to
cover threads of no.23.
3. Place no.23 through 7/8” hole
in countertop. Replace no.25 and
no.26 onto no.23 and tighten
with a wrench at bottom side of
countertop.
2. Drill 7/8” hole in sheet metal.
Insert no.1 through hole and screw
no.21 on back of no.1, leaving no.20
free to turn.
3. Apply te on tape or pipe joint
compound to threads of water
supply line. Connect no.1 to water
supply line outlet, tightening as far
as possible.
4. Tighten no.20 and no.21 so they
are ush against surface of sink
back.
5. Turn on water supply and check
for leaks.
Flow Adjustment:
To adjust water ow, loosen
no.7 with a wrench, then use
screwdriver to turn no.8 to desired
setting. Tighten no.7 when ow
adjustment is complete.
1
7, 8
23
24
26
25
countertop
4. Screw no.1 into no.22 and tighten
rmly.
5. Apply te on tape or pipe joint
compound to threads of no.23,
connect to water supply line inlet.
6. Turn on water supply and check
for leaks.
To adjust water ow see ow
adjustment note for B-1200-R
model.
22
General Instructions
sink back
7, 8
20
21
1
