Part Number Guide
4
B-2740 Side Mount Mixer Assembly
1 Body Base w/ Supply Lines & Outlet *
A Handle Kit 013113-45
B Cartridge 013080-45
C Index, Temperature 014173-45
D Trim Ring 016661-45
E Locking Nut 016663-45
F Inlet & Outlet Hose 013537-45
G Set Screw 016675-45
2 Deck Mounting Ring *
3 Deck Mounting Ring O-Ring *
4 Threaded Locking Rod *
5 Brass Lock Nut *
6 Locking C-Ring *
Gooseneck Assembly for: B-2741 B-2742 B-2746
7A Gooseneck BL-5570-02 133X B-2403
7B Aerator B-0199-07 B-0199-06 B-0199-01
8 Center Body Assembly B-0430 B-0431 B-0431
9 Center Body Shank * * *
10 Washer 000999-45 000999-45 000999-45
11 Nut 002954-45 002954-45 002954-45
Gooseneck Assembly for: B-2743 B-2744 B-2749
7A Gooseneck 000398-40
7B Aerator B-0199-06 B-0199-06
8 Center Body Assembly B-0431 B-0431 009435-40
9 Center Body Shank * * *
10 Washer 000999-45 000999-45 000999-45
11 Nut 002954-45 002954-45 002954-45
12 Set Screw 001486-45 001486-45
13 Valve Body *
14 Diverter Valve 002338-45 002338-45 002338-45
15 Guide Assembly 001496-45 001496-45 B-KF
16 Shank * * N/A
17 Combo Nut Washer * * N/A
18 Side Spray Assembly B-0101
Side Spray, 4’ 001495-45 001495-45
Side Spray, 7’ 013659-45 013659-45
