Tangent Medix KW User Manual



ModelName
VITAKW
MedixKW
Mainboard
SandyBridgeMotherboard
CPU
IntelSandyBridgeCPU,LGA1155‐pin,32nm
i5‐2390T2.7G,L26M,65W
i3‐21203.3G,L23M,65W
PentiumG8502.9G,L23M,65W
PentiumG620T2.2G,L23M,65W
CeleronG5402.5G,L22M,65W
Chipset IntelQ67PCH
(ProcessorControllerHub,AMTsupported_highend)
SystemMemory 1xLongDIMMsocketupto8GBDDR31066/1333Mhz,
standard1GB
LCD/TouchPanel 
LCDSize 15.6"LEDLCD 18.5"LEDLCD
Brightness 250nits
MaximumResolution 1366x768
TouchScreenType Trueflatresistivetouch/Trueflat projectedcapacitivetouch
Storage
HDD 2.5"SlimHDDbay,SATAHDD
Peripherals
WebCam(Build‐in) 2MWebCam
MSR‐rightside(Optional) 3Track(USB)
WiFi(Optional) 802.11b/g/nWLANcard
Expansion 
MiniPCI‐ESocket 1
ExternalI/OPorts 
USBPort 4xUSBTypeA
SerialCOM 4(RJ45type,COM1/COM2standardCOM,COM3/COM4with
+5V/+12VbyBIOSsetting)
Parallel 1xD‐sub25F
LAN(10/100/1000) 1xRJ‐45
2ndLAN(10/100/1000) 1xRJ‐45
2ndVGA 1xDB15F
CashDrawer 1xRJ‐11(12Vor24V)
AudioJack 1xMic‐in,1xLine‐out
DCJack 1x2pinCN
e‐SATA BlindHole
PowerButton 1
ThermalSolution 
ThermalSolution 1xFan 2xFan

21
