Tangent Medix KW User Manual



6‐1‐2.Connectors&Functions
Connector Purpose
CN1 PowerButtonConnector
CN3 PrinterPortReset
CN4 PrinterPort
CN5/8 HDDPower
CN11 COM5ForTouch
CN13 CardReaderConnector
CN14 Lineout
CN15 HDDLED
CN16 Speaker&MIC
CN18 MICIN
CN20/JP10 SystemIndicator
CN22 USBPort
CN23 PS2KEYBOARD
CN26 LVDS
CN27 InverterConnector
CN29 SystemFan
DDR3_A1 DDR3SO‐DIMM1
DDR3_A2 DDR3SO‐DIMM2
PRN1 ParallelPort
PWR1 +19VDCJack
RJ11_1 CashDrawerConnector
RJ45_1 COM1,COM2,COM3,COM4
RJ45_2 LAN
SATA1 SATAConnector
SATA2 SATAConnector
USB1 USB1,USB2
USB2 USB3,USB4
SW1 PowerButton
JP1 CMOSOperationMode
JP3/6 VGAPort
JP4/5 COM2RS232/485/422Setting
JP8 LCDIDSetting
JP9 PowerModeSetting
JP12 SystemReset
JP14 InverterSelection
JP18 COM3/4PowerSetting
JP19 CashDrawerPowerSetting
25
