4. PRODUCT FEATURE IDENTIFICATION:
Note that the 601 PI models have the transformer pre-attached to the inside of the 601 PI back-can, whereas the
501 models have the transformer pre-attached to the speaker assembly.
Fig 1.1: The blind-mount (BM) models come with a pre-fitted back-can
Fig 1.2: A pre-install (PI) model shown without optional pre-install back-can
Fig 1.3: Optional pre-install (PI) back-can for PI models
Conduit/Cable Clamp
Euro Type Connector
Mounting Wings
hctiwS yratoRtroP gninuT
Screws for
mounting wings
Screws for
mounting wings
Tuning Port
rotcennoC epyT oruEhctiwS yratoR
Conduit Knock-out points
Euro Type Plug
Euro Type Connector
5. ACCESSORIES:
Each product is supplied with the following accessories as standard:
C-Ring Tile bridge kit
Note: A tile bridge kit
must always be used
when installing into
suspended ceiling tiles
Grille Cut-out template
Paint Mask
CMS
Optional accessories:
Foam port-plug
NOTE: Only supplied with PI
models for applications where
PI models are being installed
without back-cans. Do not use
the foam port-plug if you are
installing the PI product into a
back-can.
Plaster (Mud) Ring
Safety Notice: In order to comply with UL regulations, the PI back-can must always be used with the CMS PI models.
