Tannoy CMS501 User Manual

DO NOT OVERTIGHTEN!
6
6.1 MECHANICAL INSTALLATION GUIDE FOR SUSPENDED CEILINGS
Slide the tile panel back into the suspended ceiling. The tile bridge ends will catch over
the railings, supporting the weight of the speaker.
5
Slide the speaker assembly through the hole and turn the screws on the front of the
speaker to extend the mounting wings. Tighten the screws until a firm grip is achieved.
If using a power driver, Tannoy recommends a torque setting of 1.5Nm.
4
Place the C-ring and tile-bridge on top of the ceiling panel, aligning the C-ring over the
hole, and screw the C-ring to the tile bridge using the fixings provided.
3
Cut out the hole in the ceiling tile using a hole saw or pad saw.
2
Remove the ceiling tile from its frame and place it on a flat surface. Mark the
cut-out area on the ceiling tile by tracing around the template provided.
1
Go to section 7 for instructions on wiring and set-up.
6.2 MECHANICAL INSTALLATION GUIDE FOR SHEET-ROCK (PLASTER BOARD) CEILINGS
Slide the speaker assembly through the hole and turn the screws to extend the mounting
wings. Tighten the screws until a firm grip is achieved.
If using a power driver, Tannoy recommends a torque setting of 1.5Nm.
4
DO NOT OVERTIGHTEN!
Go to section 7 for wiring and set-up instructions then return to point 4 below.
3
Cut out the hole in the ceiling using a hole saw or pad saw, then slide the
C-ring into the ceiling, aligning it over the cut-out hole).
2
Mark the cut-out area on the ceiling by tracing around the template provided.
1
7
Insert grille by pushing it onto the speaker.
5
CMS
