8. Mounting and flying
8.2 Mounting and flying hardware
Wall Bracket–EachVLSSeriesloudspeakerissuppliedwithastandardwallbracketsuitableformount-
ingonmostwallsurfaces.ThebracketissuppliedastwointerlockingUplates.Oneplateattachestotherear
oftheloudspeakerwithfoursuppliedscrews.Theotherpartissecuredtothewall.Thebaronthebottomof
thespeakerplateslidesintothebottomnotchofthewallplate,whilethetopissecuredwiththetwosupplied
screws.ThebracketfortheVLS7and15isslottedtoallowananglebetween0and6degrees(Fig.3).Aligning
thetoptwoscrewholesoftheVLS30resultsinaatushmount;usingthelowertwoscrewpositionsprovides
a4degreedownwardtilt.(Fig.4)
Fig.3 VLS 7 & VLS 15 Fig.4 VLS 30
Flying Bracket–EachVLSSeriesloudspeakerisalsosuppliedwithayingbracket.Thebracketisattached
tothetoptwoinsertsusingthesuppliedM6screws(Fig.5).Thetwobottominsertscanbeusedaspullback
ifrequired.
