Tannoy VLS 15 User Manual

VLS Series Operation Manual rev 1.1.0
15
10. Technical Specifications
10. Technical Specifications
10.3 VLS 30
Ordering Information
Part Number Colour
8001 7020 Black
8001 7021 White
Thisproductisenvironmentallyprotected
toIP65ratedstandard.
Notes:
1. Averageoverstatedbandwidth.Measuredin

 anIECbafeinanAnechoicChamber
2. Unweightedpinknoiseinput,measuredat
 1metreonaxis

3. Longtermpowerhandlingcapacityasdened
 inEIA-426Btest
Afullrangeofmeasurements,performance
data,CLFandEase™DataforVLS30canbe
downloadedfromwww.tannoypro.com.
Tannoyoperatesapolicyofcontinuousresearch
anddevelopment.Theintroductionofnewmaterials
ormanufacturingmethodsmayintroducevariations
inactualperformance;however,actualperformance
alwayswillequalorexceedthepublished
specications,whichTannoyreservestherightto
alterwithoutpriornotice.Pleaseverifythelatest
specicationswhendealingwithcriticalapplications.
Copyright(c)2014TannoyLimited.Allrightsreserved.
Performance
Frequency response (-3 dB)
(1)
120Hz-22kHz
Frequency range (-10 dB)
(1)
90Hz-35kHz
System sensitivity (1 W @ 1 m)
(2)
94dB
Horizontal dispersion (-6 dB)
130degreeshorizontal
Vertical dispersion (-6 dB)
+3degrees/-11degrees(-4degreebias)
Driver complement
14x3.5”(89mm)woofers
16x1”(25mm)metaldometweeters
Crossover
PassivenetworkutilisingFocussedAsymmetricalShapingTechnology(FAST)
Crossoverpoint2.5kHz
Directivity factor (Q)
15averaged1kHzto10kHz
Directivity Index (DI)
11.8averaged1kHzto10kHz
Power Handling
(3)
Average 400W
Programme 800W
Peak 1600W
Recommended Amplier Power
1200W@4ohms
Nominal Impedance (Lo Z)
6ohms
Rated maximum SPL (1 M, Lo Z)
(2)
Average 120dB
Peak 126dB
Transformer Taps (via front rotary switch)
70 V
150W/75W/37.5W/19W/9.5W/5W

OFF&lowimpedanceoperation
100 V
150W/75W/37.5W/19W/9.5W

OFF&lowimpedanceoperation
Distortion
10% full power Harmonics
2nd 3rd
250 Hz
1.60% 0.91%
1 kHz
0.14% 0.15%
10 kHz
0.63% 0.26%
1% full power
250 Hz
0.57% 0.43%
1 kHz
0.06% 0.06%
10 kHz
0.21% 0.14%
Physical
Enclosure
Aluminiumextrusion
Finish
PaintRAL9003(white)&RAL9004(black)

CustomRALcoloursavailable(additionalcostandlead-time)
Connectors
Barrierstrip
Fittings
Flyingbracket,wallmountbracket,inputpanelcoverplateandgland
Dimensions (H x W x D)
1460.5x121x146mm(57.5x4.8x5.7”)
Net Weight (ea)
20kg(44lbs)
Packed Quantity
1
