VLS Series Operation Manual rev 1.1.0
15
10. Technical Specifications
10. Technical Specifications
10.3 VLS 30
Ordering Information
Part Number Colour
8001 7020 Black
8001 7021 White
Thisproductisenvironmentallyprotected
toIP65ratedstandard.
Notes:
1. Averageoverstatedbandwidth.Measuredin

 anIECbafeinanAnechoicChamber
2. Unweightedpinknoiseinput,measuredat
 1metreonaxis

3. Longtermpowerhandlingcapacityasdened
 inEIA-426Btest
Afullrangeofmeasurements,performance
data,CLFandEase™DataforVLS30canbe
downloadedfromwww.tannoypro.com.
Tannoyoperatesapolicyofcontinuousresearch
anddevelopment.Theintroductionofnewmaterials
ormanufacturingmethodsmayintroducevariations
inactualperformance;however,actualperformance
alwayswillequalorexceedthepublished
specications,whichTannoyreservestherightto
alterwithoutpriornotice.Pleaseverifythelatest
specicationswhendealingwithcriticalapplications.
Copyright(c)2014TannoyLimited.Allrightsreserved.
Performance
Frequency response (-3 dB)
(1)
120Hz-22kHz
Frequency range (-10 dB)
(1)
90Hz-35kHz
System sensitivity (1 W @ 1 m)
(2)
94dB
Horizontal dispersion (-6 dB)
130degreeshorizontal
Vertical dispersion (-6 dB)
+3degrees/-11degrees(-4degreebias)
Driver complement
14x3.5”(89mm)woofers
16x1”(25mm)metaldometweeters
Crossover
PassivenetworkutilisingFocussedAsymmetricalShapingTechnology(FAST)
Crossoverpoint2.5kHz
Directivity factor (Q)
15averaged1kHzto10kHz
Directivity Index (DI)
11.8averaged1kHzto10kHz
Power Handling
(3)
Average 400W
Programme 800W
Peak 1600W
Recommended Amplier Power
1200W@4ohms
Nominal Impedance (Lo Z)
6ohms
Rated maximum SPL (1 M, Lo Z)
(2)
Average 120dB
Peak 126dB
Transformer Taps (via front rotary switch)
70 V
150W/75W/37.5W/19W/9.5W/5W

OFF&lowimpedanceoperation
100 V
150W/75W/37.5W/19W/9.5W

OFF&lowimpedanceoperation
Distortion
10% full power Harmonics
2nd 3rd
250 Hz
1.60% 0.91%
1 kHz
0.14% 0.15%
10 kHz
0.63% 0.26%
1% full power
250 Hz
0.57% 0.43%
1 kHz
0.06% 0.06%
10 kHz
0.21% 0.14%
Physical
Enclosure
Aluminiumextrusion
Finish
PaintRAL9003(white)&RAL9004(black)

CustomRALcoloursavailable(additionalcostandlead-time)
Connectors
Barrierstrip
Fittings
Flyingbracket,wallmountbracket,inputpanelcoverplateandgland
Dimensions (H x W x D)
1460.5x121x146mm(57.5x4.8x5.7”)
Net Weight (ea)
20kg(44lbs)
Packed Quantity
1
