BFM-505, 506, 507 Finish Mower
Hopper Assembly
Item
Part # Description Qty.
FM50001 Safety Guard - BFM 500 Series
OS357210 Oil Seal M35 x 72 x 10
SRE-72 Snap Ring - 72mm external
FM50004 Shim
B6207 Bearing 6207
FM50006 Input Shaft
KM100830 Key M10 x 8 x 30
FM50008 Ring Gear
B30207 Bearing 30207
10 BM0812520 Bolt HH M8-1.25x20 Galv. 8.8
11 FM50011 Housing
12 OP1615V Oil Plug vented M16-1.5
13 LW08 Washer lock M8
14 FM50014 Cap - Gearbox
15 FM50015 Gasket - Gearbox Cap
16 OSP1415 Sight Plug M14 x 1.5
17 BM1217545 Bolt HH M12-1.75x45
18 FM50018 Output Shaft
19 B32008AX Bearing 32008AX
20 KM100840 Key - M10 x 8 x 40
21 FM50021 Spacer
22 FM50022 Shim
23 B30208 Bearing 30208
24 OR40x2.65 Oil Ring - M40 x 2.65
25 FM50025 Bevel Pinion Spacer
26 OS508010 Oil Seal M50 x 80 x 10
27 SLNM4015 Spanner Locking Nut M40-1.5
28 FM50028 Stop Washer
29 BM1217535 Bolt HH M12-1.75x35 Galv. 8.8
30 FM50030L-60 Belt Cover for BFM 505 LH 1
FM50030L-72 Belt Cover for BFM 506 LH 1
FM50030L-84 Belt Cover for BFM 507 LH 1
30A FM50030R-60 Belt Cover for BFM 505 RH 1
FM50030R-72 Belt Cover for BFM 506 RH 1
FM50030R-84 Belt Cover for BFM 507 RH 1
31 FW08 Washer flat M8
32 FM50032 Gearbox Plate
33 FM50033 Gearbox Support Plate
34 BM101585FT Bolt HH M10-1.5x85 8.8 zinc (full thread)
