BFM-505, 506, 507 Finish Mower
Hopper Assembly
Item
Part # Description Qty.
35 BM1012530 Bolt M10-1.25x30
36 FM50036A Dust Cap
37 RC4 M4 R-Clip
38 FM50038A Hitch Block - 505, 506
FM50038B Hitch Block - 507
39 FM50039 Hitch Pin
40 FM50040 Pivot Hitch Pin
41 BM1217535 Bolt M12-1.75x35
42 FM50042-72 Deck - 74" BFM - 506
FM50042-84 Deck - 84" BFM - 507
43 LYNPN08 Lynch pin- M8
44 FM50044 Spacer - Cutting Height 1 1/4"
45 FM50045 Bushing- Wheel Arm
46 FM5046 Spacer - Cutting Height 1"
46A FM50046A-60 Wheel Arm - BFM-505
FM50046A-72 Wheel Arm - BFM-506
FM50046A-84 Wheel Arm - BFM-507
47 FM50047 Spacer - Cutting Height 5/8"
48 FM50048 Spacer - Cutting Height 1/2"
49 FM50049 Spacer - Cutting Height 1/4"
50 FM50050A Wheel Yoke for BFM 505, BFM 506
FM50050B Wheel Yoke for BFM 507
51 FM50051A Tire - Hard Tire (000 - 6923Y) for BFM-505, BFM-506
FM50051B Tire - Hard Tire (004 – 4131) for BFM-507
52 FM50052 Spacer- Wheel 8
53 B6205-2RS Bearing- 6205-2RS
54 FM50054 Bushing- Wheel
55 BM12175130 Bolt- M12-1.75x130 (BFM 505 & 506)
BM12175180 Bolt- M12-1.75x180 (BFM 507 Only)
56 GN081S Grease Fitting- M8 x 1 Straight 3
57 SLNM2515 Locking Spanner Nut- M25-1.5 3
58 FM50058 Single Pulley
59 FM50059-60 V-BELT BFM-505 (B68 - 17 x 1727)
FM50059-72 V-BELT BFM-506 (B74 17 x 1880)
FM50059-84 V-BELT BFM-507 (B82 17 x 2083)
60 BM1012530 Bolt M10-1.25x30 14
61 FM50061 Spindle Hub
62 FM50062 Spacer
