Tar River BFM-506 - Page 29

29
BFM-505, 506, 507 Finish Mower
Frame Assembly
Item
Part # Description Qty.
63 FM50063 Spindle Shaft (version 2)
FM50063A Spindle Shaft (version 1, threaded for nut)
64 KM080835 Key- M8 x 8 x 35
65 FM50065 Dust Cover Gasket
66 FM50066 Dust Cap
67 FM50067 Adapter Plate for Blade
68 FM50068-60 Blade - BFM-505
FM50068-72 Blade - BFM-506
FM50068-84 Blade - BFM-507
69 BM1212535 Center Bolt- M12-1.25x35
70 FM50070 Double Pulley
71 FM50071-A Double Drive Pulley - BFM-505
FM50071-B Double Drive Pulley - BFM 506 & BFM 507
72 FM50072-A A-Frame Support - BFM 505 & BFM 506
FM50072-B A-Frame Support - BFM 507
73 FM50073 A-Frame Strap - BFM-505= -60, BFM-506= -72, BFM-507= -84
74 BM12175125 Bolt M12-1.75x125
75 FM50075 Top Link
76 FM50076 Top Hitch Pin
76A FM50077 Spacer - Top Link
77 BM1217575 Bolt M12-1.75x75
FW12 Flat Washer- M12 Used with BM1217575
LW12 Lock Washer- M12 Used with BM1217575
78 FM50078 Bracket for Roller- BFM-507 Or BFM-505 & 506 (Optional)
79 FM50079 Roller- BFM-507 (BFM-505 & 506 Optional)
80 FM50080 Shaft for Roller BFM-507 (BFM-505 & 506 Optional)
81 BM081016 Bolt HH M8-1.0x16
82 BM101520 Bolt HH M10-1.5x20
83 LW10 Washer lock M10
84 FM50084 Gearbox complete
85 FM50101 Complete Spindle Assembly
86 LFW16 Large Flat Washer M16
87 LNM12175 Nut self-locking M12-1.75
88 FW12 Washer flat M12
89 MSTSC061 Set Screw M6-1.0
90 BM1217535 Bolt HH M12-1.75x35 Galv. 8.8
91 FM10062 PTO Complete, BFM-505
FM10063 PTO Complete, BFM-506, 507
92 FW18 Washer flat M18
93 LNM1815 Nut self-lock M18-1.5
