Target windham accent cabinet - Step 1: Attach Right Side Panel to Bottom Panel

7
step 1: attach right side panel to bottom panel
(H1) x 2
wooden dowel
(H2) x 2
cam bolt
(H3) x 2
cam
1.1. Carefully tap small wooden dowels into place in right side panel. Leave 1/2” of the dowels sticking out.
1.2. Screw-In cam bolts must be screwed down ush in right side panel.
1.3. Refer to page 6 for instructions on how to use the cam lock system. Do not over tighten bolts.
