15
20. Remove the PTO shear bolt.
21. Slide the PTO shaft onto the gearbox shaft.
22. Replace the snap ring.
23. Align the shear bolt holes, install, and tighten PTO
shaft shear bolt.
24. Assembly of your Rotary Cutter is not complete.
Please read the next section of this manual
for filling the gearbox with oil, lubricating
instructions, and sizing your PTO (if applicable).
ASSEMBLY
