Spirit Digital 328 v2
6
The DA-78HR menus must be configured as illustrated in the table below in order to complete
the setup.
To enter the DA-78HR menus, press the <SHIFT> key so that the LED is illuminated, indicating
that the unit is in 'shift' mode. Press the <MENU> switch - 'System' should appear in the display.
To enter the menu press the <SUBMENU> switch until the time mode submenu appears in the
display. Use the up and down cursor keys (<AUTO MON> / <ALL INPUT>) to set the values
as below.
DA-78HR Menu Submenu Recommended setting Notes
System - - time mode Abs
d. in TDIF
Audio 1
TDIF 24
24 bit is optimum wordlength –
ensure that this setting is also set in
the 328 Tape Port Select menu
dith off
The 328 adds dither to 16 and 20 bit
signals
frm mode
Same as 328 setting
tc - - out tc tmg digital
out tc src tape tc
MIDI on Enables MMC and MTC
MTC on
MIDI Fast MTC on
DA-78HR transmits timecode when in
fast wind mode
Stop MTC on
DA-78HR transmits timecode when
stopped
Tascam DA-78HR
Tascam DA-78HRTascam DA-78HR
Tascam DA-78HR
3
Pages 23-25 of the DA-78HR manual should be consulted when setting
up the unit with the configuration below
NOTE
