9.0 DRAWINGS & PARTS LIST
ITEM DESCRIPTION QTY PART
1 10-24 X 1/2 SOCKET HEAD CAP SCREW 1 VT10-24SH500
2 PALM BUTTON - RED ANODIZE 1 UE250
3 RETAINING RING 11/16" EXTERNAL 1 VR4285
4 BUTTON SPRING 1 UE205
5 PROPORTIONING KNOB 1 UE240
6 SPRING HELICAL COMPRESSION 3 VM4195
7 3/16" BALL - TORLON 3 V2120-TORLON
8 O-RING-008 3/16 ID 1/16 C/S 1 VO-008
9 BACK FLUSH PIN 1 UE220
10 O-RING-115 11/16 ID 3/32 C/S 1 VO-115
11
BALL 60 GPM - NO GROOVES 1 UE230
BALL 95 GPM - 1 GROOVE 1 UE231
BALL 125 GPM - 2 GROOVES 1 UE232
BALL 225 LPM 1 UE233
BALL 450 LPM 1 UE234
12 7/64 X 5/8 HDP SPIROL PIN 1 VP109X625H
13
METER LABEL 60 GPM 1 UL200
METER LABEL 95 GPM 1 UL201
METER LABEL 125 GPM 1 UL202
METER LABEL 225 LPM @11 BAR 1 UL207
METER LABEL 450 LPM @ 11 BAR 1 UL208
METER LABEL 225 LPM @ 10 BAR 1 UL203F
METER LABEL 450 LPM @ 10 BAR 1 UL204F
14 METER HEAD 1 UE235
15 BALL 3/8" - POLYETHYLENE 1 VB375PE
16 SEAT: PROPORTIONING BALL 1 UE335
17 O-RING-117 13/16 ID 3/32 C/S 1 VO-117
18 BARB FITTING 1 UE310
19 HOSE CLAMP 2 UE340
20 SUCTION HOSE 1"ID 1.25"OD CLEAR 1 UE320
21 SUCTION WAND 1 UE330
22 SPRING - LOCKER RING 1 UE215
23 O-RING-219 1 VO-219
24 LOCATION RING 1 UE245
25 1/4" BALL - 302 STAINLESS STEEL 6 V2125
26 LOCKER 1 UE210
27 CHECK DISK 1 UE225
