©Copyright Task Force Tips, Inc. 2004 - 2017 LIU-330 November 16, 2017 Rev08
19
ITEM DESCRIPTION QTY PART
28
NAME LABEL - 60GPM EDUCTOR 2 UL210
NAME LABEL - 95GPM EDUCTOR 2 UL211
NAME LABEL - 125GPM EDUCTOR 2 UL212
NAME LABEL - 225 LPM @ 11 BAR 2 UL217
NAME LABEL - 450 LPM @ 11 BAR 2 UL218
NAME LABEL - 225 LPM @ 10 BAR 2 UL213F
NAME LABEL - 450 LPM @ 10 BAR 2 UL214F
29
EXIT 60 GPM 1.5"NPSH - NO GROOVES 1 UE100IF
EXIT 60 GPM 1.5"NH - NO GROOVES 1 UE100NF
EXIT 95 GPM 1.5"NPSH - 1 GROOVE 1 UE101IF
EXIT 95 GPM 1.5"NH - 1 GROOVE 1 UE101NF
EXIT 125 GPM 1.5"NPSH - 2 GROOVES 1 UE102IF
EXIT 125 GPM 1.5"NH - 2 GROOVES 1 UE102NF
EXIT 225 LPM @ 11 BAR 1.5” BSP 1 UE133BF
EXIT 450 LPM @ 11 BAR 1.5” BSP 1 UE124BF
EXIT 225 LPM @ 10 BAR 2.0” BSP 1 UE133BH
EXIT 450 LPM @ 10 BAR 2.0” BSP 1 UE134BH
EXIT 450 LPM @ 10 BAR 2.5” BSP 1 UE144BJ
30 INTERSECTION 1 UE120
31 O-RING-216 1-1/8 ID 1/8 C/S 1 VO-216
32
BLENDING TUBE 60GPM - NO GROOVES 1 UE110
BLENDING TUBE 95GPM - 1 GROOVE 1 UE111
BLENDING TUBE 125GPM - 2 GROOVES 1 UE112
BLENDING TUBE 225 LPM @ 11 BAR 1 UE116
BLENDING TUBE 450 LPM @ 11 BAR 1 UE117
BLENDING TUBE 225 LPM @ 10 BAR 1 UE113
BLENDING TUBE 450 LPM @ 10 BAR 1 UE114
33 3/16" BALL - 302 STAINLESS STEEL 34 V2120
34 O-RING-134 1 VO-134
35 1/4-28 X 3/16 SET SCREW 1 VT25-28SS187
36
COUPLING 1.5"NPSH 1 HM697I
COUPLING 1.5"NH 1 HM697N
37 GASKET - 1.5" HOSE COUPLING 1 V3130
38
COUPLING 2.5"NH ROCKERLUG 1 HM677N
COUPLING 2.5"NPSH ROCKERLUG 1 HM677I
39 GASKET - 2.5" HOSE COUPLING 1 V3190
40 CHECK SPRING 1 UE228
41 O-RING-214 1 VO-214
42 5/16-18 X 1/4 SOCKET SET SCREW 2 VT31-18SS250
Parts 11, 29, and 32 are fl ow calibrated as indicated by the number of grooves.
CAUTION
Do not intermix metering heads with eductor bodies of diff erent fl ow rates. Intermixing can
cause weaker or stronger foam than expected resulting in risk of injury as the ability to control
the fi re is compromised.
