TASKalfa 4002i - Page 68

To Next Page

To Previous Page

2-3

Installing and Setting up the Machine > Part Names (Machine Exterior)

21 Paper Length Guide

22 Paper Width Guide

23 Paper Width Adjusting Tab

24 Support Tray Section of the Multi Purpose Tray

25 Multi Purpose Tray

26 Paper Width Guide

27 Right Cover 1 Lever

28 Right Cover 1

22 23
