37
Typ 1700 1800
Theoretical performance area operation
width x drive speed (4) x 1000
3500 4250 m2/h
Working width 700 850 mm
Squeegee width 990 1150 mm
Cleaning solution tank / recovery tank 85 85 l
Machine speed forward / backwards 5/3 5/3 km/h
Machine weight / for operation (max.) 155/430 157/480 kg
Rated voltage 24V 24V dc
Tools 2 x 350 2 x 430 mm
Brush rpm 150 133 min-1
Brush pressure 42/61 60 kg
Dimensions (L x W x H) 156 x 77 169 x 90 x 100 mm
Rated power 1500 1700 W
Splash water protection IPX3 IPX3
Assessed sound level LPA according to
EN 60704-1
<70 <70 dB(A)
The assessed effective acceleration value
according to ISO 5349
0.184 0.184 m /s2
Electrical protection class III III
CSD (Cleaning Solution Dosing) yes yes
Recycling yes option
