Taski swingo 2500 User Manual

24
Overview
1 Tube holder
2 Full recovery tank probe
3 Recycling filter (optional)
4 Drainage hose
5 Suction hose
6 Tank lid
7 Squeegee
8 Solution supply pipe and filter
9 Recovery tank
10 Rear wheel steering unit
11 Solution tank (bag-in-tank) with dosing aid
12 Battery disconnection socket
13 Brush unit
14 Metal bumper
15 Parking brake
16 Drive pedal
17 Brake pedal
18 Drive / reverse lever and horn
19 Keyswitch
20 Control panel
21 Steering wheel
22 Driver seat with adjustment lever
23 Driver seat with safety contact
24 Battery cover (main fuse and battery plug)
25 Tank hood
26 Suction filter
27 Brush button ( +/- for pressure)
28 Solution button ( +/- for quantity)
29 Display control button
30 Slow speed button
31 Suction unit button
32 Service indicator
33 Recovery tank full indicator
34 Empty cleaning solution indicator
35 Display screen when turning on
36 Suction aggregate on
37 Suction aggregate off (recovery tank full)
38 Tool aggregate on
39 Pedal error indicator
40 Battery indicator
41 Hour counter
42 Service hour counter
43 Tool aggregate hour counter
44 Brush pressure display
45 Solution level display
46 Error code
1
2
3
4
5
6
78
9 10 13
14
15
16
17
18
19
20
2122
23
242526
11 12
Display
36
42434445
41
37383940
28
27
29
30 31 32 33 34 35
46
