Technical Manual
31. May 2007 Revision: V1.10 3-3
Copyright © 2007, JohnsonDiversey, Inc.
05.0 swingo 450B - technical data.fm - 31. May 2007
3.2.3 Dimensions and weights
Battery capacity (maintenance-free) (Ah)/C5 -50
Battery autonomy (max.) (h) 1.5
Max. working speed km/h 3
Internal charger BMS models
Protection grade IP IPX3
Protection -
Protection class charger II
Approvals SEV/ TUV / OVE
Vibration (m/s2) 0.25
Pos. Value
Dimensions (handle in working position) L/W/H (mm) 1340/480/920
Dimensions (handle in parking position) L/W/H (mm) 1050/480/980
Dimensions (shipping position without clean water
tank assy)
L/W/H (mm) 1050/480/785
Battery compartement L/W/H (mm) 275/354/204
Weight, ready to use (kg) 123
Weight, ready for shipping (kg) 62
Max. floor pressure (N/mm2) 0.86
Turn radius (mm) 1050
Wheel diameter (mm) 200
Castor diameter (mm) 100
Table 4: Dimensions and weights
Pos. Value
Table 3: Technical Data
