Technical Manual
31. May 2007 Revision: V1.10 5-8
Copyright © 2007, JohnsonDiversey, Inc.
07.0 swingo 450B - software u parameters.fm - 31. May 2007
The Configbox has an LC-Display (2x16 characters) and 2 buttons (Select/Next). It
allows easy changing of the changeable parameters and reading out data and hours.
The communication is only in english and higher than version 1.1. The Configbox con-
tains a 9V battery (6LR61/6AM6 or MN1604) and can only communicate with assem-
bled and working electronic.
The connection is the same as for the computer software
5.2.2 Safety points
Whenever you open the dashboard, you must switch off the
machine (B-models) or unplug first from mains power (E-models).
Never directly touch the components on the board with your hand
or fingers.
5.2.3 Requirements
• TASKI swingo (series models)
• Configbox
• Adapter cable set 4122673 (17606-39): Software, Cable
5.2.4 Step by Step
• Switch off machine / unplug the mains driven machines
• Remove the electrical cover
• Connect the PC with the machine
• Assemble the electrical cover again, but do not fix it in such a
way that you squash the PC connection cable
If you do not assemble the cover it is not possible to switch on the
machine
Remarks
Follow the menu guide
5.2.5 Menu Guide
