Technical Manual
31. May 2007 Revision: V1.10 4-16
Copyright © 2007, JohnsonDiversey, Inc.
06.0 swingo 450B - technical procedures.fm - 31. May 2007
Picture 14: Waterflow dirty water
4.5.3.2 Water flow dirty water
1 Squeegee
2 Tank cover assy
3 Recovery tank
4.5.3.3 Air flow
A. Recovery tank
B. Tank cover assy
C. Vacuum motor
