Technical Manual
31. May 2007 Revision: V1.10 8-4
Copyright © 2007, JohnsonDiversey, Inc.
09.5 swingo 450B - recommended spare parts.fm - 31. May 2007
8.2.6 Chassis (06)
8.2.7 Brush drive (07)
8.2.8 Magnetic valve, electrical parts (08)
Pos. No. Ord. No. Art. No. Description Class Note
103 4096120 19511-34 Pedal Pad OM
123 4122743 17605-30 Limit Switch OM
Table 5: Tool lowering unit
Pos. No. Ord. No. Art. No. Description Class Note
106 4122563 17603-30 Castor Compl. Blue OM
109 4125935 17450-92 Battery Charger 6A EM
133 4122570 17602-61 Carrying Wheel 200 W
147 4039680 8909/61 Lubricant Synsetral
53B P Kg
Table 6: Chassis
Pos. No. Ord. No. Art. No. Description Class Note
111 4122594 2157/013 Poly-V-Belt 6 EPJ 508 OM
114 4079540 2530/107 Ball Bearing 6007 2
RS
OM
123 4122595 2157/014 Poly-V-Belt 10 EPJ
675
OM
127 4122555 17603-01 Pulley OM
130 4122440 14604-26 Sealing Ring OM
134 4122441 14604-27 Centre Plug OM
135 4122705 17602-91 Coupling, Brush OM
147 4123215 17608-38 Sealing Ring OM
Table 7: Brush drive
