MNL291
20
4 POWER CONNECTORS
4.1 12VDC24VDC POWER CONNECTOR FOR IP65
4.2 POWER CONNECTION ACCESSORIES
4.2.1 100-240VAC POWER CONNECTOR FOR IP65
Pin No. Symbol
1 L
2 N
3
POWER CONNECTION INDICATION
