FOOT PLATE
Assembly Instructions
NO.
SPARE PART NAME NOTE
QTY
1 Foot plat assembly 1
1
44
Multi Smith Pro
2.4 Optional Accessories
2.4.1 Scope of Delivery - Foot Plate
The scope of delivery consist of the following parts. At the beginning, check whether all parts
and tools belonging to the device are included in the scope of delivery and whether damage has
occurred. In the event of complaints, the contractual partner must be contacted directly.
⚠ CAUTION
If parts of the scope of delivery are missing or damaged, the assembly must not be carried out.
2.4.2 Assembly - Foot Plate
Attach the foot plate (1) with the pins to the hooks of the barbell rod (41), see illustration.
