Taylor MagnaBlend SB25 User Manual

4-2
OPERATOR PARTS IDENTIFICATION
Model SB25
Operator Parts Identification
4
SB25 Exploded View Parts Identification
Item Description Part No.
1 Cover A.-Hopper 081239
2 Hopper-Ice *Small-Clear 081238
3 Grate-Right 081227
4 Pan 081219
5 Rod-Pivot-Actuator 081220
6 Actuator-Rinse 081221
7 Grate-Left 081228
8 Guard-Splash 081122
9 Chute-Shaver 081121
Item Description Part No.
10 Lid-Pour-Pitcher (115V) 081248
11 Pitcher-Blender- Unguarded 
(115V Machines)
083605
12 Pitcher A.-Guard (230V
Machines)
083605-GB
13 Hose A.-Bib (115V) X82350
14 Coupling-Bulkhd-1/4-Valved-Q 081191
15 Coupling-3/8 Barb-Valved 081886
16 Adapter-3/8 Tube-1/4 QD 081216
17 Tube-.250ID x.375OD 083296-60
