ES100 ESS Unit user manual
14
2. Complete insert the battery into the bracket as figure3-5, pay attention to pushing the battery to
the buckle position.
Figure 3-5
3. Place another bracket in the rear of the battery and push it to the buckle position.
Figure 3-6
4. Stack the required number of battery and bracket combinations as described above, and fasten
the upper and lower buckles. Shown as Figure3-7.
Figure 3-7
