MPPT charge controller User Manual
3. Installation and Wiring
3.1 Pre-installation inspection
3.1.1 Check outer packing
Please check the outer packing for damage before unpacking, and check the machine model. If
there have something wrong, please don’t open it and contact your dealer.
After unpacking, please check the deliverable for completeness and any apparent damage.
If any item is missing or there is any damage, please contact your dealer.
Table 3-1 Packing list
Packing list
Description NO.
MPPT charge controller 1
User manual 1
3Pin connector 1
2Pin connector 1
3.2 Select installation location
3.2.1 Requirement
The protection level of charger is IP31, which can only be installed indoors.
During the operation of the radiator, the temperature of the chassis and radiator will be relatively
high. Please do not install it in the place where it is easy to touch.
Do not install in the place where inflammable and explosive articles are stored.
Do not install in the place where children can touch it.
Do not install on flammable building materials
Please ensure that the mounting surface is firm enough to meet the load bearing requirements
of charger installation
Do not install SP in a sealed compartment containing batteries.
