MPPT charge controller User Manual
2
Tab le 5-1 Battery charging voltage
Battery type Average voltage Float voltage
Charging
ratio
GEL/OPzV
Default setting
：
14.1V
Setting range
：
14.0~14.5V
Default setting
：
13.7V
Setting range
：
13.0~14.0V
0.15C
AGM
Default setting
：
14.4V
Setting range
：
14.0~14.5V
Default setting
：
13.5V
Setting range
：
13.0~14.0V
0.15C
Lead-Carbon
Default setting： 14.1V
Setting range：14.0~14.5V
Default setting：13.5V
Setting range：13.0~14.0V
0.2C
Flooded
Default setting
：
14.7V
Setting range
：
14.0~15.0V
Default setting
：
13.5V
Setting range
：
13.0~14.0V
0.15C
Customerize
Default setting
：
14.2V(12/24V)
Setting range：13.0~14.5V
Default setting
：
13.7V (12/24V)
Setting range：13.0~14.0V
0.2C
Default setting
：
13.5V(48V)
Setting range
：
13.0~14.5V
Default setting
：
13.3V(48V)
Setting range
：
13.0~14.0V
Traction
Default setting
：
15.2V
Setting range
：
14.0~15.5V
Default setting
：
13.5V
Setting range
：
13.0~14.0V
0.15C
OPzS
Default setting： 14.7V
Setting range：14.0~15.5V
Default setting：13.4V
Setting range：13.0~14.0V
0.15C
BMS (Guanyu)
Default setting： 14.525V
Setting range
：
14.0~15.0V
Default setting：14.525V
Setting range
：
14.0~15.0V
0.15C
Note
：
Above is charge voltage for a standalone battery of 12VDC. The charge voltage for
24VDC or 48VDC please just times 2 or 4 respectively
5.6 User Control
Users can realize the rapid configuration of the system according to requirements. The following
submenus are included under this interface.
>Screen Set
Date & Time
>User Control
>Screen Set
Display Setting range Description
Backlight_KeepOn
1-Enable
；
0-Disable
Default setting:0-Disable
Constant backlight
enablement.
Page_Turn_Auto
3~30s
Default setting:5s
Automatic page turning time
of real-time information
display interface;3~30s can
be set, and the page will
automatically turn after
timeout.
>Data & Time From this page, you can set the current time.
