MPPT charge controller User Manual
2
>Para_Battery
Min_Bulk_Time
1~600min
Default setting:120min
Minimum bulk time setting.
Max_Absorp_Time
1~240h
Default setting:8h
Maximum absorption time
setting.
Auto_CHG_Cycle
24~2400h
Default setting:240h
Equalization cycle time.
CHG_T_Compensate
0-Disable
1-Enable
Default setting: 0-Disable
Charging temperature
compensation coefficient
CHG_TEMP_Coef
-30~0mV/℃(12V)
-60~0mV/℃(24V)
-120~0mV/℃(48V)
Default setting:
-18mV@12V,-36mV@24V,
-72mV@48V
Enable the charging
temperature
compensation.
BAT_OT_WARN_Gate
35~65℃
Default setting:55℃
The over temperature
warning of BAT setting
In EQ Setting, there are the following Setting options.
Display Setting range Description
EQ_Command
0-Off 1-On
Default setting: 0-Off
Equalization charging
control
U_EQ_CHG
15.5~16.3V
Default setting:15.6V
Equalization charging
voltage range setting of
battery (The setting range
of the equalization
charging voltage is a
standalone battery of
12VDC.
For 24VDC or
48VDC please just times 2
or 4 respectively).
EQ_Sustain_Time
30~90min
Default setting: 30min
Equalization charging time
setting.
>Change
Password
Changing the password for parameter setting.
>Setup Wizard See setup wizard refer to chapter 6.7.
>Reset
Parameter
Display Description
Reset User_Para Restore Factory Defaults.
