2.2 Structure
2.2.1 Front
Figure 2-1 MPPT charge controller structure in front view
Tab le 2-1 Control Buttons
Button Function

Cancel the selection.

Display the previous level of menu.

Display the previous page.
 Increase the value of the selected item.

Press the button for more than 2 seconds to scroll the page up.

Display the next page.
 Decrease the value of the selected item.

Press the button for more than 2 seconds to scroll the page down.
 Enter into this menu, displaying the next level.

Select and confirm the selection of a menu item.
Table 2-2 LED directive function
LED Definition Function
Solar  It illuminate when SP is power on.
Charge
 It Flash when SP is in float charging state.
 It illuminate when SP is perform charging.
Fault
 It Flash when SP have warning.
 It illuminate when SP have error.
