MPPT charge controller User Manual
2
>Para_Battery
Battery_Type
0- GEL/ OPzV
1- AGM
2- Lead-Carbon
3- Flooded
4- Customerize
5- Traction
6- OPZS
7- BMS (Guanyu)
Default setting:GEL/ OPzV
Battery type setting.
Select 3,5,6 to unlock EQ
function. The default
charging voltage of
different batteries is shown
in Table 5-1.
Battery_AH
20~2000AH
Default setting:200AH
Battery capacity setting
In Advanced Set, there are the following Setting options.
Display Setting range Description
U_Absorp_CHG
Please refer to Table 5-1
Default setting:14.1V
The average charging
voltage of battery.
Note: This value will be
changed when changing
the battery type，
users can
reset it with their
requirements.
U_Float_CHG
Please refer to Table 5-1
Default setting:13.7V
The float charging voltage
of battery.
Note: This value will be
changed when changing
the battery type, users can
reset it with their needs.
BAT_OV_Warn
(U_AVE_CHG +
0.2)~17.0V
(The minimum value is
12V, and the maximum
value is depended by the
battery type.)
Default setting:14.9V
The over voltage warning
of battery.(The setting
range of the over voltage
warning is a standalone
battery of 12VDC.
For
24VDC or 48VDC please
just times 2 or 4
respectively)
CHG_MAX_Current
3
~Rate_CHG_CUR (The
maximum value is 40A)
The maximum charging
current of the system.
Note: This value will be
changed when changing
the battery capacity, and
users can reset it with their
needs.
